Specifications

• Dimenzije

  add remove
  • Dužina:
    2415 mm
  • Seat height, unladen:
    680 mm
  • Ground clearance:
    120 mm
  • Rake (steering head):
    30
  • Trail:
    140 mm
  • Wheelbase:
    1630 mm
  • Tires, front specifications:
    130/90B16,73H,BW
  • Tires, rear specifications:
    150/80B16,77H,BW
  • Kapacitet goriva:
    18.9 l
  • Oil capacity:
    4.4 l
  • Weight, as shipped:
    316 kg
  • Weight, in running order:
    330.21 kg
  • Luggage capacity – volume:
    1.5 cu ft (0.043 m³)
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 114
  • Bore:
    102 mm
  • Stroke:
    114 mm
  • Displacement:
    1868 cm³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-2 shorty dual; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    161 Nm
  • Engine torque (RPM):
    3000
  • Horsepower:
    94 HP / 70 kW @ 4750 rpm
  • Lean angle, right (deg.):
    27.3
  • Lean angle, left (deg.):
    28.5
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    47 mpg (5 l/100km)
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions :
    128 g/km CO₂
• Pogonski sklop

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Front fork:
    Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" covers
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 56mm stroke; hydraulic preload adjustment
  • Wheels, front type:
    Base model: Gloss black, 9-spoke cast aluminum; Anniversary model: Chrome, 9-spoke cast aluminum
  • Wheels, rear type:
    Base model: Gloss black, 9-spoke cast aluminum; Anniversary model: Chrome, 9-spoke cast aluminum
  • Brakes, type:
    Solid, uniform expansion rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    All LED, low beam, high beam and signature position lamp, Incandescent Zeppelin tail lamp, Incandescent bullets, Incandescent bullet light bar
  • Gauges:
    5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
