Specifications

• Dimenzije

  add remove
  • Dužina:
    2320 mm
  • Seat height, unladen:
    680 mm
  • Ground clearance:
    125 mm
  • Rake (steering head):
    30
  • Trail:
    157 mm
  • Wheelbase:
    1630 mm
  • Tires, front specifications:
    100/90B19,57H,BW
  • Tires, rear specifications:
    150/80B16,77H,BW
  • Kapacitet goriva:
    13.2 l
  • Oil capacity:
    3.8 l
  • Weight, as shipped:
    282 kg
  • Weight, in running order:
    293.02 kg
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 117 Classic
  • Bore:
    103.5 mm
  • Stroke:
    114.3 mm
  • Displacement:
    1923 cm³
  • Compression ratio:
    10.3:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-1; catalyst in header
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    163 Nm
  • Engine torque (RPM):
    2500
  • Horsepower:
    98 HP / 73 kW @ 4600 rpm
  • Lean angle, right (deg.):
    28.5
  • Lean angle, left (deg.):
    28.5
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    47 mpg (5 l/100 km)
• Pogonski sklop

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Front fork:
    Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; gaiter covers
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
  • Wheels, front type:
    Black, Annihilator cast aluminum
  • Wheels, rear type:
    Black, Annihilator cast aluminum
  • Brakes, type:
    Solid, uniform expansion rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
